Zipcord Interconnect Fiber Optical Cable

    Description:

    ZCC simplex cable  use single Φ900μm or Φ600μm flame-retardant tight buffer fiber as optical communication medium, the tight buffer fiber wrapped with a layer of aramid yarn as strength member unit, and the cable is completed with a PVC or LSZH (Low smoke, Zero halogen, flame-retardant) jacket


    Characteristics:

    •Tight buffer fiber easy of stripping

    •Tight buffer fiber have excellent  fire-retardant properties

    •Aramid  yarn as strength member make cable have excellent tensile strength

    •Figure 8 structure jacket facilitate embranchment

    •The jacket anti-corrosion, anti-water, anti-ultraviolet radiation, flame-retardant and •harmless to environment etc.

    •All dielectric structure protect it from electromagnetic influence

    •Scientific design with serious processing art


    Applications:

    •Duplex Optical fiber jumper or pigtail

    •Indoor riser level and plenum level cable distribution

    •Interconnect between instruments, communication equipments


    Standards:

    Comply with Standard YD/T 1258.2-2003, ICEA-596, GR-409, IEC 60794-2-10/11, etc; and meet the requirements for UL approval for OFNR and OFNP


    Transport/Storage/Operating Temperature:-20℃~+60℃,Installation Temperature:-5℃~+50℃




    Zipcord Interconnect Fiber Optical Cable
