UnitubeFireproop Fiber Optical Cable

    Description:

    The fibers, 250μm, are positioned in a loose tube made of a high modulus plastic. The tubes are filled with a water-resistant filling compound. The tube is wrapped with a layer of PSP longitudinally. Between the PSP and the loose tube water-blocking material is applied to keep the cable compact and watertight. Two parallel wires are placed at the two sides of the steel tape. The cable is

     completed with a polyethylene (PE) sheath.


    Characteristics:

    •Good mechanical and temperature performance

    •High strength loose tube that is hydrolysis resistant

    •Special tube filling compound ensure a critical protection of fiber

    •Special sheath material ensures excellent flame-retardant performance

    •Crush resistance and flexibility

    •PSP enhancing moisture-proof

    •Two parallel steel wires ensure tensile strength

    •Small diameter, light weight and friendly installation



    Standards:Complies with Standard YD/T 769-2003.


    Storage/Operating Temperature:-40℃ to + 70℃


    Note:

    Suffix Xn denotes fiber type and see details in  optical fiber illustration.

    The colour arrangements of fiber and tube are specified in the colour identification table.

    The nominal value of the PE jacket thickness is 1.6mm.

    Need more detailed information please consult local sales representative.

    The optical cable shouldn’t stored in outdoor environment more than one year.
