Self-supporting Bow-type drop cable GJXFCH

    Description:

    The optical fiber unit is positioned in the centre. Two parallel Fiber Reinforced Plastics (FRP)are placed at the two sides. A steel wire as the additional strength member is also applied. Then, the cable is completed with a black or color LSZH sheath


    Characteristics:

    •Special low-bend-sensitivity fiber provides high bandwidth and excellent communication transmission property;

    •Two parallel FRP strength members ensure good performance of crush resistance to protect the fiber;

    •Single wire as the additional strength member ensures good performance of tensile strength;

    •Simple structure, light weight and high practicability;

    •Novel flute design, easily strip and splice, simplify the installation and maintenance;

    •Low smoke,zero halogen and flame retardant sheath.


    Storage/Operating Temperature:-20℃ to + 60℃


    Delivery Length:Standard Reel Length: 2000 m; Other lengths available on request.




    Self-supporting Bow-type drop cable GJXFCH
